Yost Model 880-D2 8 Inch Multi-Purpose Reversible Combination Vise with Swivel Base
100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.
- • Lifetime Tech Support
Product Overview:
Description
This reversible combination vise system is a fusion of a pipe and bench vise designed for more rugged applications. This industrial-grade vise has a bench jaw opening that can reach up to 8.5 inches but when reversed can open up to 12.5 inches. For the pipe jaw's throat depth 4.75 inches then when reversed 3.25 inches.
- Constructed in Heavy Duty 65,000 P.S.I. Ductile Iron
- Machined Inch T Inch Bar for Precision Fit
- Expandable Versatile Vise by Reversing Front Jaw Two (2) Options
- Large Dual Anvils (1) Upper 4.1 Inch X 4 Inch (1) Lower: 8 Inch x 3.25 Inch
- Lower Anvil Converts to Product Support Shelf when Reversing Front Jaw
- Replaceable Hardened Steel Top Jaws: Serrated and Reversible to Smooth
- Replaceable Hardened Steel Serrated Pipe Jaws
- Removable / Replaceable Pipe Jaws are Designed to Grip Pipe Securely
- Swivel Base Securely Mounts to Work Bench (4 - Bolts by Others)
- Interlocking Swivel Base 360 degree Motion Equipped with (2) Lockdowns
- Continuous Rolled Main Screw Thread
- Balled Screw Handle Supplied with Safety Rubber Washers
Yost Vises has been producing high-quality vises and vise accessories since 1908. We supply our products to both large distributors and individual craftsmen throughout the world ranging from industrial-grade vises, professional-grade vises, workshop-grade vises, light to heavy-duty vises, multifunction vises, welding vises, etc. Our products meet or exceed the Industrial Standard of Federal Specification GGG-V-410A, providing consumers with quality products that last for years at a great price.
Warranty
Specifications
Model Number: | 880-D2 |
Jaw Width (nominal inches): | 8 |
Jaw Opening (nominal inches): | 8.5 (Reversed = 12.5) |
Throat Depth (nominal inches): | 4.75 (Reversed = 3.25) |
Min Pipe Capacity (nominal inches): | 0.125 |
Max Pipe Capacity (nominal inches): | 4.5 |
Base: | Swivel |
Material: | Ductile Iron |
NSN: | No |
Packaging Dimensions: | 23.5 inches x 10.5 inches x 16.5 inches |
Shipping Weight (lbs): | 69 |
Country of Origin: | China |
In the Box
Contents
(1) Yost Model 880-D2 8 Inch Multi-Purpose Reversible Combination Vise
