Description

Set of 6 Mobile Column Lifts

When you need to lift beyond what most shops even consider possible, put 6 mobile column lifts in your shop. The best part: you don’t even have to use all 6 at once. Break them up into set of 4, lifting multiple heavy-duty trucks up to 72,000 lbs. These mobile lifts make up BendPak’s most powerful lifting system to date. If you need to lift more than 40,000 lbs., mobile column lifts are your best bet.

Features:

  • 18,000-lb. individual column capacity
  • Meets or exceeds the standards prescribed by ANSI/ALI ALCTV-2017
  • Just three 30’ cables are used leaving the front or back of the lift clear of cable obstructions
  • Intuitive controls allow the lift to be fully programmed and controlled from any column
  • Smart electronics feature self-diagnostics and selfcalibration functions
  • Sealed and enclosed linear potentiometers feature precision potentiometric output and high-frequency response for precise synchronization and communication of all columns through all cycles for precise, level lifting
  • Height settings can be programmed for low ceiling shops

Specifications

<table class=''specs''> <tr> <td>Lifting Capacity</td> <td>18,000 lbs. (8,165 kg)</td> </tr> <tr> <td>A - Overall Height (RAISED)</td> <td>101” (2,565 mm)</td> </tr> <tr> <td>B - Overall Height (LOWERED)</td> <td>146.5” (3,721 mm)</td> </tr> <tr> <td>C - Max. Lifting Height</td> <td>71.5” (1,889 mm)</td> </tr> <tr> <td>D - Overall Depth</td> <td>48.75” (1,238 mm)</td> </tr> <tr> <td>E - Overall Width</td> <td>45” (1,143 mm)</td> </tr> <tr> <td>F - Chassis Length</td> <td>32.25” (819 mm)</td> </tr> <tr> <td>G - Min. Lifting Fork Width</td> <td>9.5” (241 mm)</td> </tr> <tr> <td>H - Max. Lifting Fork Width</td> <td>35” (889 mm)</td> </tr> <tr> <td>I - Lifting Fork Length</td> <td>11.5” (292 mm)</td> </tr> <tr> <td>Turning Circle</td> <td>40” (1,016 mm)</td> </tr> <tr> <td>Column Weight</td> <td>1,450 lbs. (657 kg)</td> </tr> <tr> <td>Lifting Speed</td> <td>85 sec</td> </tr> </table>

Warranty

<p><a href="https://www.bendpak.com/Portable-Column-Lift-Warranty-BendPak.pdf" target="_blank"><i><b>Warranty</b></i></a></p>

Shipping

  • Shipping: Shipping is included in the price of this item.
  • Delivery Time: This item ships directly from the manufacturer - Please allow 2-3 weeks for delivery time
  • Residential Delivery: This item may only be shipped to a business address and a forklift must be available to unload.
  • Delivery: Will be delivered truck and will require a forklift to unload. You must have a forklift to unload from truck.

https://www.bendpak.com/BendPak-Products-Flatbed-Exclusive.pdf

https://www.bendpak.com/BendPak-Delivery-Information-Form.pdf

Fork Lift Required for Delivery

Instructions

<p><a href="https://www.bendpak.com/PCL-18B-Mobile-Column-Lift-Manual-5900170-BendPak.pdf" target="_blank"><i><b>User Manual for Part # 5175297</b></i></a></p>
