DeVilbiss GPG GRAVITY (7E7 - 1.2 - 1.3 - CUPPED) 905022

Product Overview:


DeVilbiss has been at the forefront of developing spray guns specific to applications around the body shop, including meeting the market’s demand for a cost-effective, multi-purpose spray gun. The DeVilbiss GPG addresses this requirement by providing solid performance that is durable and an exceptional value.

The anodized, drop-forged aluminum gun body of the GPG provides renowned ergonomics together with lightweight aluminum controls and smooth trigger action. It’s this legendary combination of fit, feel and performance that makes the DeVilbiss brand the professional automotive refinisher’s preferred choice.

The high-efficiency and HVLP air caps have been developed to provide excellent atomization of a wide range of automotive refinish paints and coatings. The large array of fluid nozzles offers a wide range of flow rates allowing for rapid application rates for a multitude of coatings including clearcoats, basecoats, sealers, primers, enamels, synthetics and other common commercial paints.


  • Lightweight design delivers a uniform spray pattern and atomization distribution for an exceptional quality finish that professional painters demand
  • Range of advanced air cap technologies for excellent application performance with the latest waterborne and solventborne coatings
  • Ergonomic handle design with reduced trigger travel to decrease operator fatigue
  • Environmental legislation-compliant atomization with high transfer efficiency resulting in significant paint savings
  • Drop-forged aluminum, anodized gun body with removable air baffle for a longer working life


Air Cap: 7E7
Needle/Nozzle: 1.2, 1.3
Gauge: HAV-555
Cup Type: 900ml, ALUMINUM
Weight (gun only): 500g
Gun Body: Anodized Aluminum
Air Cap: Plated Brass
Air Cap Retaining Ring & Knobs: Black Anodized Aluminum
Fluid Nozzle: Stainless Steel
Fluid Needle: Stainless Steel
Air Inlet Thread: 1/4" Universal

Air Cap Offerings

Air Cap Atomization Type Applications Recommended Inlet Pressure (PSI) Max Air Consumption (SCFM) Fan Pattern Size (In.) Nozzle Sizes
7E7 High Efficiency Basecoats, Clearcoats 16-22 10.8 9.5-10.5 1.2-1.4mm
GPG2 HVLP Basecoats, Clearcoats 22-26 15.9 11.5-12.0 1.2-2.2mm
C86 Conventional Basecoats, Clearcoats 29-44 10.6 10.5-11.5 1.4-1.8mm
C30 Conventional Basecoats, Clearcoats 29-58 10.8 9.5-10.5 1.4-1.8mm
PR10 High Efficiency Primers 26-29 12 10.5-12.0 1.4-2.5mm
PR30 HVLP Primers 17-21 16 11.0-13.0 1.4-2.5mm
