Item # 22439 BRAND: Earl's

Earls Auto-Flex Hose - Size 6 - Sold By The Foot In Continuo

Tough Stainless Steel Wire Braid-Protected Synthetic Rubber Hose. Easy to Cut and Assemble. Accepts Swivel-Seal, Auto Fit & Auto-Crimp Hose Ends.
Tough Stainless Steel Wire Braid-Protected Synthetic Rubber Hose. Easy to Cut and Assemble. Accepts Swivel-Seal, Auto Fit & Auto-Crimp Hose Ends.
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getAggregateRating, 33.15ms
  • REVIEWS, PRODUCT
  • bvseo-msg: HTTP status code of 404 was returned;
$10.95
Loading...
Save for Later
Tough Stainless Steel Wire Braid-Protected Synthetic Rubber Hose. Easy to Cut and Assemble. Accepts Swivel-Seal, Auto Fit & Auto-Crimp Hose Ends.

100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.

  • • Lifetime Tech Support
Earls Auto-Flex Hose - Size 6 - Sold By The Foot In Continuo

Product Overview:

Description

A high quality stainless steel braided hose at a price competitive with the imports. Earl's AUTO-FLEX stainless steel braid-protected synthetic rubber hose is manufactured to our specifications in the U.S.A. Earl's AUTO-FLEX hose features a recommended temperature range and maximum operating pressure equal to our racing premium quality Perform-O-Flex hose...at a much better price. A partial coverage textile inner braid is imbedded in the liner during manufacture. The hose is finished with a full coverage stainless steel braid which is bonded to the reinforced liner. The liner is known as H.T.E ( not to be confused with PTFE ) and it is the highest quality of synthetic neoprene liner on the market. Continuous use temperature rating is - 40 to + 350 degrees F. Auto-Flex hose is intended for use with Swivel-Seal, Auto-Fit and Auto-Crimp hose ends only. No other Earl's hose ends are intended for use with Auto-Flex hose. The use of other manufacturers hose ends is also not recommended with this hose as it does not work with lower quality import fittings. PSI rating is determined by many factors including hose end in use and assembly method.

Features:

  • Stainless Braid
  • Protects Synthetic Rubber Hose
  • Competitive Price
  • Made in the USA
  • Textile Braid Imbedded in Hose Liner
  • Clean and Fast Flowing
  • Sold per foot

Warranty

1 Year Manufacturers Warranty

Specifications

<b>Brand:</b>Earls<br /> <b>Compatible Hose:</b> Auto-Crimp, Auto-Fit, Econ-O-Fit, Swivel-Seal<br /> <b>Emission Code:</b> 5<br /> <b>Fluid Type:</b> Automatic Transmission Fluid, Coolant, Diesel, E85, Methanol/Alcohol, Oil, Pump Gas, Race Gas<br /> <b>Fluid Type Rating - Automatic Transmission Fluid:</b> 5 out of 5 Rating<br /> <b>Fluid Type Rating - Coolant:</b> 5 out of 5 Rating<br /> <b>Fluid Type Rating - Diesel:</b> 2 out of 5 Rating<br /> <b>Fluid Type Rating - E85:</b> 2 out of 5 Rating<br /> <b>Fluid Type Rating - Methanol/Alcohol:</b> 1 out of 5 Rating<br /> <b>Fluid Type Rating - Oil:</b> 5 out of 5 Rating<br /> <b>Fluid Type Rating - Pump Gas:</b> 2 out of 5 Rating<br /> <b>Fluid Type Rating - Race Gas:</b> 3 out of 5 Rating<br /> <b>Fluid Type Rating - Vacuum:</b> 5 out of 5 Rating<br /> <b>Hose Family:</b> Auto-Flex<br /> <b>Hose Length:</b> BULK<br /> <b>Hose Outer Material:</b> Stainless Steel<br /> <b>Hose Size:</b> 6 AN<br /> <b>I.D. to O.D. Concentricity Range:</b> .020"<br /> <b>Inside Diameter:</b> .329" TO .369"<br /> <b>Max Vacuum:</b> 27 in Hg<br /> <b>Max Working PSI:</b> 1500 PSI<br /> <b>Maximum Continuous Length:</b> 50 Feet<br /> <b>Min. Bend Radius:</b> 2.5"<br /> <b>Outside Diameter:</b> .527" TO .570"<br /> <b>Product Type:</b> Hose<br /> <b>Submersible in Fuel:</b> No<br /> <b>Temperature Range:</b> -40° to 350° F<br /> <b>Part Number:</b> 300006ERL<br /><br /> <b>EMMISIONS</b><br><br> <p>This part is legal for sale or use on Emissions Controlled Vehicles, Uncontrolled (Non-Emissions Controlled) Vehicles, and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations.</p>

In the Box

Contents

(1) Earls Auto-Flex Hose - Size 6 - Sold By The Foot In Continuous Length up to 50 feet 300006ERL

Guides & Accessories

Instructions

<p><a href="https://documents.holley.com/earls_guide.pdf" target="_blank"><i><b>Earl's Selection Guide For Part #AT809106ERL</b></i></a></p>
