Item # 55132 BRAND: Eastwood Elite

Eastwood Elite 4 x 4 CNC Plasma Table with CNC 60 Amp Plasma Cutter

Start Your Business Today with an Eastwood 4x4 CNC Plasma Cutting Machine
Start Your Business Today with an Eastwood 4x4 CNC Plasma Cutting Machine
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getAggregateRating, 18.85ms
  • REVIEWS, PRODUCT
  • bvseo-msg: HTTP status code of 404 was returned;
$7,999.99
Out Of Stock. Due back March 19
Save for Later
Start Your Business Today with an Eastwood 4x4 CNC Plasma Cutting Machine

1 year Warranty Included

Add an Eastwood Service Plan for additional protection?

Learn More

100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.

  • • 90 Day Returns
  • • Lifetime Tech Support
Eastwood Elite 4 x 4 CNC Plasma Table with CNC 60 Amp Plasma Cutter

Product Overview:

Description

Eastwood Elite 4' x 4' CNC Plasma Cutting Machine with FREE 60 Amp Plasma Cutter

This machine is designed for the professional cutting up to 3/8” plate all day or the small fabricator cutting a variety of materials and shapes. Combine the large 4' x 4' work surface with the robust welded frame design and this unit will handle sheets up to 1000 lbs., making it great for nearly any job. Included FREE is our Inverter Powered 60 amp plasma power supply that cuts cleanly through 3/8’ steel plate with unmatched accuracy, cut quality and reliability. It’s backed by a 1-year warranty and our lifetime tech support. Now is the time to start a new hobby, business, or expand your current business with another CNC table.

The Eastwood 4' x 4' CNC Plasma Cutting Table Features:

  • CNC Table operates on standard 120 volt AC input
  • 60 Amp Plasma Cutter operates on 240 volt AC input
  • Intuitive interface with easy to use touch screen
  • CNC Controller makes it easy for beginners, yet has the features a pro requires
  • Dedicated CNC Controller so you don't have to supply a laptop to operate the machine
  • Robust 3 axis stepper motors assure long life and accurate cuts
  • Heavy gauge welded frame design assures a rock-solid foundation
  • Rigid design for precise gantry movements and cutting accuracy
  • Long 23' torch cable on CNC Table
  • Steel table construction holds 60.23 Gallons
  • Large Waterbed: 59.05" X-Axis; 62.99 -Axis; 3.75" Z-Axis
  • Torch travel is 49.2" in both X-Axis and Y-Axis
  • Leveling feet for accurate height adjustment
  • Plasma Cutter has a 60% Duty Cycle at 63 Amps and 100% at 49 Amps
  • Includes everything to get started - all you need is a CAD file
  • Backed by Eastwood's 1-year warranty

    Precise Metal Cutting Accuracy

    This innovative, affordable, Elite CNC Plasma Cutting Machine was designed and developed by Eastwood's own R&D staff and tested in-house on the same type of real-life projects you'll be doing. The intuitive interface and touch screen controls are simple enough for a beginner yet loaded with the features the professionals need.

    The quality stepper motors combined with the heavy duty frame provides the rock-solid foundation you require for the accuracy you demand. This Elite CNC Machine includes everything you need to start cutting, including a FREE 60 Amp Plasma Cutter, all you have to supply is the CAD file!

    WARNING: Beware of lesser units that don't include a quality waterbed, sturdy fully welded frame construction, integrated control panel so you don't have to also purchase a laptop computer, precise torch height control or an included plasma cutting machine. Eastwood supplies all of this and more!

    NOTE: The Guides & Accessories Tab has Product Instructions, Uncrating Instructions for when your machine arrives as well as a free file to download to use with Fusion.

    Warranty

    1 Year Warranty

    Specifications

    CNC Table Specifications

  • Power Input: 120V, 50/60Hz, 1Ph, 1.25A
  • Power Plug: NEMA 5-15P
  • Table Construction: Steel
  • CNC Torch Travel: 49.2" X-Axis and Y-Axis; 2.5" Z-Axis
  • CNC Torch Hose and Wire Length: 23'
  • Waterbed Size: 59.05" X-Axis; 62.99" Y-Axis; 3.75" Z-Axis
  • Waterbed Size: 60.23 Gallons (228 Liters)
  • Movement Accuracy: ± 0.1mm
  • Cutting Accuracy: ± 0.5mm


    60 Amp Plasma Cutter Specifications

  • Power Input: 240V, 50/60 Hz
  • Power Plug: NEMA 6-50P
  • Air Input: 1/4” NPT Female Thread
  • Output Current Adjustment: 10-63 Amps
  • Duty Cycle: 60% @ 63 Amps; 100% @ 49 Amps
  • Arc Ignition Mode: High Frequency
  • Plasma Torch and Hose Length: 12.3'
  • Ground Cable Length: 9'
  • Plasma Cutter Weight: 54.5 lbs
  • Plasma Cutter Dimensions: 10.83" x 22.44" x 18.70"
  • Shipping

    Fork Lift Required for Delivery

    In the Box

    Contents

  • (1) Eastwood Elite 4’ x 4’ CNC Plasma Table Assembly that includes Stepper Motors, Torch, Control Panel and Mount, Wiring, Tracks, Waterbed, Toothed Steel Slats, all assembled
  • (1) 60 Amp CNC Plasma Cutter
  • (4) Leg Assembly with Leveling Foot
  • (1) Plasma Cutter Shelf Bottom
  • (1) Plasma Cutter Shelf Left Side
  • (1) Plasma Cutter Shelf Right Side
  • (24) M1 2x 35 Socket Cap Screw
  • (28) M12 Washer
  • (4) M12 x 25 Socket Cap Screw
  • (4) M12 Nut
  • (12) M 5 x12 Socket Cap Screw
  • (12) M5 Nut
  • (1) Eastwood Elite CNC Cut 60 Plasma Cutter (Item #55133)
  • (1) Ball Drain Valve
  • (2) Table Power Switch Key
  • (2) Electrical Compartment Key
  • (1) PTFE Tape Roll
  • (1) Eastwood Instruction Manual
