SINGLE-STAGE PAINT MIXING RATIOS
Thoroughly mix three parts single-stage urethane paint with one part Activator. No additional reduction is required but can be used as needed. Use caution in mixing materials as Eastwood’s single-stage urethane paint may begin to gel after approximately two hours (at 70 °F).

PAINT GUN SET-UP
HVLP Gun: Fluid Tip 1.3-1.5 mm Inlet Spray Pressure 25-30 psi
Conventional Gravity: Fluid Tip 1.3-1.6 mm Inlet Spray Pressure 45-50 psi
Conventional Siphon: Fluid Tip: 1.4-1.8 mm Inlet Spray Pressure 45-50 psi

APPLICATION INSTRUCTIONS
Apply single-stage urethane paints in two to three medium wet coats as necessary to achieve sufficient coverage, allowing ten minute flash between coats. Additional coats may be necessary to achieve total coverage for some metallic colors. A final “fog coat” may be applied with metallic colors to help set an even flake pattern and /or adjust flake orientation. A dry film thickness of approximately 2 mil is recommended. Paint should be dust free within 10-15 minutes and tack-free within one hour (at 70 °F). Re-coat anytime after the previous coat has flashed, or before 18 hours. After 18 hours, paint should be abraded prior to re-coating for proper adhesion purposes.

This urethane paint may be applied as a stand-alone single-stage system, or in combination with Eastwood’s High Solids Urethane Clear as a basecoat/clearcoat system. Additionally, Urethane Clear may be integrated into Urethane color. When combining the two systems, be sure to activate each side (the paint and the clear) separately, with their own activators at the correct mix ratios, before blending.

When used as a Single-Stage Urethane Paint, this coating may be wet-sanded and polished for increased depth and gloss like any other urethane topcoat. Care should be taken when lightly cutting metallic colors to prevent disturbing aluminum flake.
(Q) Do I need a clear?
(A) No, but you should use a clearcoat over metallics.

(Q) How much paint do I need?
(A) Typically one gallon per car. If you are also painting jambs, under the hood, or the trunk, use 2 gallons. For large cars and pickup trucks, use 2 gallons. Number of coats, prep and application methods will affect the amount of paint required.

PRE Painting Prep
Concours HVLP Paint Guns
Air Filters and Dryers
6" Liquid Ice Buffing Kit
Epoxy Primers
Urethane Primers
Polyester Primers
Clear Coats

Click here to download safety data sheet

Always wear proper eye, skin and respiratory protection. Always paint in a well-ventilated area away from sparks and open flame. Consult MSDS and product data sheets for proper safety precautions.

Click here for paint chip chart
