Eastwood 180 Amp MIG Welder
Operating on either 120V or 240V power, Eastwood's MIG 180 welder is as versatile as it is powerful, capable of handling steel from 24-ga to 5/16-in thick.
Operating on either 120V or 240V power, Eastwood's MIG 180 welder is as versatile as it is powerful, capable of handling steel from 24-ga to 5/16-in thick.
Operating on either 120V or 240V power, Eastwood's MIG 180 welder is as versatile as it is powerful, capable of handling steel from 24-ga to 5/16-in thick.
3 year Warranty Included
Add an Eastwood Service Plan for additional protection?
Learn More
100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.
- • 90 Day Returns
- • Lifetime Tech Support
Price for all checked items:
Product Overview:
Description
Packed with the latest IGBT inverter technology and quality features, the Eastwood MIG 180 delivers precision welds on sheet metal and other light steel and stainless steel projects up to 5/16-in. thick. This versatile 180-Amp welder runs on either 120V or 240V household power and weighs less than 26-lbs for go-anywhere portability.
Experienced welders as well as beginners will appreciate the MIG 180’s professional-quality features and construction. A tack-weld setting allows for perfectly timed short pulses, perfect for plug welds and spot welds. It also includes 2T and 4T controls for greater precision and comfort, especially for long welds.
The MIG 180 includes a Tweco-style torch that uses commonly available consumables. It doubles as a flux-core welder for gas-free welding and can also weld aluminum with the addition of an optional spool gun (Eastwood Item # 20172). With all these great features, the MIG 180 matches the overall performance of more expensive welders. And it’s all backed up by Eastwood’s 3-year warranty and lifetime tech support.
Eastwood MIG 180 Features:
- Versatile dual-power MIG welder runs on either 120V or 240V
- Welds mild and stainless steel up to 5/16-in thick
- Latest IGBT inverter technology makes it lightweight and precise
- Tack setting delivers precisely timed tack welds to prevent overheating
- 2T & 4T settings offer greater precision and comfort
- Tweco-style torch uses commonly available consumables for convenience
- Optional spool gun allows for welding aluminum
- Metal drive motor for smooth operation
- 30% duty cycle at 180 amps (60% at 130 amps)
- Backed by Eastwood's no-hassle return policy and 3-year warranty
Warranty
Specifications
| Rated Electrical Input: | 240 VAC; 29.6 AMP 120 VAC; 24 AMP |
| Required Breaker Size: | 30 amp |
| Power Voltage: | 1 Phase, 120VAC / 240VAC, 60 Hz |
| Power Cord Receptacle Plug: | NEMA 6-50R |
| Max Voltage at No Load: | 61 V DC |
| Rated Duty Cycle: | 120V: 30% @ 90 Amps 120V: 60% @ 65 Amps 120V: 100% @ 50 Amps 240V: 30% @ 180 Amps 240V: 60% @ 130 Amps 240V: 100% @ 100 Amps |
| Torch Consumables: | Tweco style nozzle and contact tips |
| Wire Feed Rate (IPM/Inches Per Minute): | 120V: 80 - 280 IPM 240V: 80 - 551 IPM |
| Wire Sizes: | 0.023-in. (0.6mm) – 0.035-in. (0.9mm) mig wire 0.030-in. (0.8mm) – 0.035-in. (0.9mm) flux core wire |
| Welding Wire Spool: | 4-in. and 8-in. spool, up to 11 lbs |
| Maximum Welding Thickness - Steel: | 5/16-in. |
| Output Current Range: | 120V: 30 - 120 Amps 240V: 30 - 180 Amps |
| Weight: | 25.3 lbs (11.5 kg) |
| Overall Dimensions: | 18-in. X 8.5-in. X 13.25-in. |
Shipping & Handling
In the Box
Contents
- MIG 180 Welder
- Gas Regulator with hose
- 8.5-in. Ground Clamp
- NEMA 5-15P to NEMA 6-50R Adapter Cord (240v to 120v), 2-ft.
- MIG Torch, Nozzle, 0.030-in. (0.8mm) Contact Tip and 8-ft. Cable
- Contact tip wrench
- Additional contact tips (.030-in. and .035-in.)
- Instruction Manual
- 3-Year “No Hassle” Warranty
Guides & Accessories
Instructions
Application Tips
Weld Aluminum with a Spool Gun
Many cars and trucks have aluminum parts, or you may need to weld aluminum for a metal fabrication project, and with a spool gun you can weld 14-gauge to 1/4-inch aluminum. Quickly and easily connect or remove it as needed for working on different parts and panels. The spool gun is sold separately or you can save money when you buy it together with the Eastwood MIG 180 here.
All-Around Steel and Aluminum MIG Welder
The MIG 180 comes complete (except for the gas cylinder) and is ready to weld 24 gauge to 5/16-inch mild steel and stainless. Connect the spool gun and you can also weld 14 gauge to 1/4-inch aluminum. With a 30 to 180 amp welding range, this high-quality MIG welding machine has a 30 percent duty cycle at 180 amps and a 60 percent duty cycle at 65 amps, giving you the power needed for tough projects.
The metal drive motor feeds the wire smoothly for the best operation and the infinitely adjustable wire speed and heat settings allows you to precisely control the machine. If you don't have a gas bottle, or are away from your shop, use the flux core wire for your welding project. Plus the ability to connect to either 240 or 120 volts makes this an incredibly versatile machine for any garage.
Precision Drive Motor
The drive roller mechanism, which is the heart of any MIG welder, is designed to our high specifications and delivers flawless wire feed without skipping or slipping on the wire. That's why the MIG 180 has a quality METAL drive motor. This means you'll get a great puddle and solid welds without having to go back and "touch up" spots. Beware of other units with much lower quality equipment!
High-Value Welders from Eastwood
This 180-amp MIG welder with spool gun has everything you need to get started, just add a bottle of shielding gas. It includes a precision metal drive motor, regulator with hose, Tweco-style torch, tips and accessories, modern features and technology. A "Quick Setup" welding chart specifies settings for each material thickness, eliminating guesswork and assuring complete penetration.
The unit is backed by Eastwood's No-Hassle 90-day return policy and industry leading 3-year manufacturer's warranty. We even provide tips and tricks on MIG welding in the Eastwood Garage that will get you started and improve your welding.
Consumables
Replacement Parts
12211 Contact Tip 0.02312224 Contact Tip 0.030
12226 MIG Wire 0.023
12227 MIG Wire 0.030
12225 Flux Wire 0.030
Accessories
Auto Darkening Welding Helmets
Welding Jacket
Welding Gloves
Check out the full line of Eastwood Welders and Plasma Cutters below:
MIG Welders - TIG Welders - ARC & Gas Welders - Plasma Cutters
