Item # 31638 BRAND: Eastwood

Eastwood Swing Arm Tire Changer

Eastwood Swing Arm Tire Changer
Eastwood Swing Arm Tire Changer
CHANNELLOCK 10" Straight Aviation Snips 610AS is rated 3.5 out of 5 by 8.
  • y_2024, m_4, d_15, h_3
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.41
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_7
  • loc_en_US, sid_31638, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getAggregateRating, 21.28ms
  • REVIEWS, PRODUCT
$1,574.99
Loading...
Loading...
Save for Later
Eastwood Swing Arm Tire Changer

1 year Warranty Included

Add an Eastwood Service Plan for additional protection?

Learn More
The Eastwood Service Plan Protect your purchase with comprehensive coverage 24/7 support No deductibles, no additional fees Parts & labor costs included Transferable coverage and more

100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.

  • 90 Day Returns
  • • Lifetime Tech Support
Eastwood Swing Arm Tire Changer

Product Overview:

Description

The Eastwood Tire Changer offers the ability to quickly and easily mount and dismount tires on most any steel or alloy wheels without damage. Constructed with the same pneumatic functions as other professional machines, this Tire Machine is ideal for the avid home hobbyist, race shop or small business.

Warranty

1 Year

Specifications

Rim Diameter Range:
– External Clamping: 10” to 18”
– Internal Clamping: 12” to 21”
Maximum Rim Width: 16”
Maximum Tire Diameter: 45”
Turntable Rotation Speed: 6 RPM
Power Requirements: 120 VAC, 60hz
Air Supply Operational Range: 115 to 145 PSI [8 to 10 Bar
Tire Changer Overall Usable Footprint dimensions are 70”H x 43”W x 37”D]

This machine has a tire inflator only. Bead seating jets are not included on this model.

Shipping & Handling

Liftgate Service: Is highly recommended, or sometimes required, for delivery of this product. If you have a safe method of unloading without a liftgate, you will have the opportunity to remove liftgate service at checkout. Please note that the truck driver will NOT assist in unloading the product for you. We are not responsible for personal injury or damage to the product resulting from unloading the merchandise without the benefit of a liftgate, delivery dock or forklift.

In the Box

Contents

(1) Main Tire Machine Base Unit
(1) Vertical Tower
(4) M12 Nuts
(4) M12 Washers
(1) Slide Shaft Spring
(1) Plastic Cover
(20) Mount/Dismount Shoe “Duckhead” Replaceable Plastic Glides
(20) Mount/Dismount Shoe “Ducktail” Replaceable Plastic Glides
(1) Coiled Air Hose
(1) Gauge/Fill Gun
(1) 1/4” MNPT, Male Coupler
(1) Tire Iron
(4) Rim Protectors

Guides & Accessories

Instructions

Click here for product instructions

Safety Information

Always read and fully understand the instruction manual before operating this unit. Always wear proper personal safety equipment while operating this unit.

Click here to see safety products

Accessories

57548 Eastwood Tire Machine Replacement Duck Head Feet Produced After 03/2017 (Black)
31810 Eastwood Tire Machine Replacement Duck Head Feet Produced Before 03/2017 (White)

Application Tips



Reviews

Rated 5 out of 5 by from Eastwood's tire changer had it since 2020 Bought in 2020 of July have changed over 50 Tires Plus no problems with it works like the big brand names at the dealerships that I used to work at with no problems matter of fact I think it's an easier machine to use
Date published: 2022-09-28
Rated 5 out of 5 by from Big boy toys! He’s pretty happy with it!!! He said only took him about 10 min versus 45-1 hour. Spoiled man. Big boy toys!
Date published: 2021-11-06
Rated 4 out of 5 by from Does its Job well Pretty good Machine. Does the Job well within its specs. Zero complaints. Only with it had neoprene clamps due to this being a Cycle shop
Date published: 2022-07-07
Rated 4 out of 5 by from Not used much yet. Works great on on regular tires, big tires are to handle.
Date published: 2021-10-17
Rated 3 out of 5 by from Needs refinement but decent overall Ive had this machine for almost a year now. Theres definitely room for improvement but for a brand new overhead tire machine that is around $1200 out the door its not bad. First, the wheel and tire size specs are a bit off. States that it can do a 45" diameter tire. Only on a bicycle maybe. Swing arm post to center of turntable is almost 20". Also, you could do a 15" wide wheel as long as the tire size is smaller. This machine did not have the clearance to mount up a 35x12.50r20 tire on a 20x10 wheel. The swing arm post could use just a bit more height, probably about 6". Second. The swingarm stop adjuster knob needs to be mounted higher. When using the machine to its capacity, the tire tends to want to grab that knob and move it out of adjustment which could cause damage to wheels. Third, the bead lube bucket needs to be mounted elsewhere like on the opposite side of the machine or in the front above the pedals. The bucket and bracket got damaged by a tire while using the beadbreaker because of its location. Fourth, the hook for the inflator chuck should be on the opposite side of the swing arm post so that youre not trying to reach through the swing arm/ duckbill area to use it. Lastly, the gauge on the inflator has an uncommon sequence to its readings. Most gauges are incremented by 1s, 2s or 5s. The included gauge uses no such pattern and therefore is more of a guess to the actual pressure that the tire is being inflated to. Overall im happy with the machine but will be making the modifications listed above to make it even better.
Date published: 2020-03-22
Rated 1 out of 5 by from HORRIBLE This is an absolute waste of money. It does not have the turn-table strength to mount/dismount a basic 15in tire. The description said it will handle a 40+in tire which it will not. 37in seems to be the maximum. The beadbreaker will not open/close for anything over 9in in tire width. DO NOT BUY THIS MACHINE.
Date published: 2023-12-01
Rated 1 out of 5 by from Very disappointed because of the incorrect advertisement said 45inch Doesnt fit even 35 inch tires it says its good for 45 ?
Date published: 2021-10-20
  • y_2024, m_4, d_15, h_3
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.41
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_7
  • loc_en_US, sid_31638, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getReviews, 4.58ms
  • REVIEWS, PRODUCT

Questions & Answers

Will this work with a smaller air compressor like a 28 or 30 gallon that put out about 5cfm?

Asked by: James
Thanks you for your question. The Air Supply Operational Range: 115 to 145 PSI So, if your compressor has this supply range it should operate the tire machine at 5cfm. The issue would be, if you use all the air in the tank, the recovery may be a bit slower and you will have to wait for the tank to refill with air before you continue on removing tires from wheels or braking beads.
Answered by: Wil Project Advisor
Date published: 2024-02-12

What type of oil goes into the site glass?

Asked by: Wise
I was unable to isolate the exact type of oil. I do believe it is clear low viscosity oil, and i was unable to find a company that can assist you..
Answered by: Anonymous
Date published: 2024-01-16

Are there adapters that can be added to allow it to work with motorcycle wheels?

Asked by: Jimbo
We do not offer any, sorry.
Answered by: Nick BC
Date published: 2023-05-11

What HP is the turntable motor rated at?

Asked by: mike b
The motor is about 1.5HP. This unit is rated to draw 9.2A on 120VAC power.
Answered by: Nick BC
Date published: 2023-04-12

Hello Will this machine mount a 37” off-road tire?

Asked by: Izcavazos
Yes, this machine is capable of handling tires up to 45" in overall diameter.
Answered by: Nick BC
Date published: 2022-10-13

How does it get delivered bc I don’t have a forklift or anything

Asked by: Mike224
This ships in a corrugated carton on a wooden pallet. Since you don't have a forklift we can get you liftgate service for offloading.
Answered by: Nick BC
Date published: 2022-08-21

Where is it made

Asked by: Neto
This unit is made over seas in China on our lines
Answered by: ZachC
Date published: 2022-05-27

How much does the tire changer weigh?

Asked by: Joester513
This weighs about 432 lbs. in total.
Answered by: Kelly H
Date published: 2022-08-21
  • y_2024, m_4, d_15, h_3CST
  • bvseo_bulk, prod_bvqa, vn_bulk_3.0.41
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_27
  • loc_en_US, sid_31638, prod, sort_[SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getContent, 4.18ms
  • QUESTIONS, PRODUCT
Glossary
Unsure of a term? Look it up on our Glossary powered by The Garage
Eastwood Swing Arm Tire Changer
$1,574.99
In Stock
