JET 7" x 12" Horizontal / Vertical Bandsaw HVBS-712

JET 7" x 12" Horizontal / Vertical Bandsaw HVBS-712

Item #32260-8015LG

JET HVBS-712, 7" x 12" Horizontal / Vertical Bandsaw
  1. Quantity:
    Quantity: close
    JET HVBS-712, 7" x 12" Horizontal / Vertical Bandsaw
    Item #32260
    Only $1,499.00

    In stock

  2. Quantity:
    Quantity: close
    Jet JPW Lift Gate Charge
    Item #8015LG
    Only $0.00

    In stock

$0.00

• This item ships directly from the manufacturer

• Expected delivery time is 1 – 2 weeks

• Not available in Eastwood Retail Stores

• Order may not be changed or canceled



< Back

Details

HVBS-712, 7" x 12" Horizontal / Vertical Bandsaw 414559

The JET HVBS-712 Horizontal/Vertical Metalworking Bandsaw has everything any operator needs to tackle even the toughest job. JET increased the width and height of the stand and added new features that exceed expectations. The HVBS-712 is another innovative JET product packed with features you’ve come to expect.

  • 9-7/16" x 10" work table in the vertical position
  • Rapid action vise miters to 45°
  • Improved Height and width of stand with built-in storage cabinet and chip tray
  • Adjustable material stop for repeatability
  • CSA/CUS : Following strict guidelines and electrical requirements, this JET Saw is CSA/CUS certified
  • Blade drive is a belt to sealed, hardened and ground gear drive system
  • Blade wheels are made from flanged cast iron for increased durability
  • Auto shut-off after cut
  • Adjustable ball bearing blade guides
  • Cast mounted adjustable hydraulic downfeed
  • Complete coolant system
  • Four 8" rubber wheels for ease of movement
  • 3/4" Bi-Metal blade

More info...
< Back

Contents

(1) HVBS-712, 7" x 12" Horizontal / Vertical Bandsaw 414559


Specifications

Cutting Capacity: (W x D) (In.): 7 x 12
Round at 90 Degrees (In.): 7
Round at 45 Degrees (In.): 4-1/2
Rectangle at 90 Degrees (In.): 4 x 11 / 7 x 10-3/8
Rectangle at 45 Degrees (In.): 6-1/2 x 4-1/2
Square at 90 Degrees (In.): 7 x 7
Square at 45 Degrees (In.): 4-1/2 x 4-1/2
Throat Depth (In.): 7
Head Movement (Deg.): 0
Vise Swivels (Deg.): 45
Blade Speeds (SFPM): 86, 132, 178, 260
Blade Wheel Diameter (In.): 11-3/4
Blade Length (In.): 93
Blade Size (In.): 3/4 x 0.032 x 93
Bed Height (In.): 22-1/4
Coolant Capacity (Gal.): 1
Motor (HP): 3/4 HP, 115/230V, 1Ph
Weight (Lbs.): 418
Overall Dimensions (L x W x H) (In.): 48 x 17 x 40
Drive: Step Pulley


Instructions

Click here for product instructions


Safety

Always wear eye and hand protection when working with metal. Keep all body parts away form moving parts of this machine. Please read and fully understand the instruction manual before use.


Warranty

2 Year Manufacturers Warranty


Shipping Instructions

Flat Rate Ship 130 Dollars, Free Lift Gate


Eastwood Offers Free Lifetime Technical Support


Click here for product SDS information


Attention California Residents - Proposition 65


Proposition 65 Warning WARNING - Cancer and Reproductive Harm - www.P65Warnings.ca.gov
