Item # 62304 BRAND: Stewart Warner

Stewart Warner Tach Sw Deluxe 8000 Side Winder 82181

Deluxe Sidewinder Tachometer
Deluxe Sidewinder Tachometer
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getAggregateRating, 34.76ms
  • REVIEWS, PRODUCT
  • bvseo-msg: HTTP status code of 404 was returned;
$173.99
Loading...
Loading...
Save for Later
Deluxe Sidewinder Tachometer

100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.

  • • Lifetime Tech Support
Stewart Warner Tach Sw Deluxe 8000 Side Winder 82181

Product Overview:

Description

The Deluxe-Series Gauge is the original of the Stewart Warner lineup. A vintage white and black display with a low-profile bezel pairs perfectly with street rods and classic vehicles. They are available for various application readings and in both electrical or mechanical versions.

  • Works with 4, 6, and 8-cylinder engines
  • The dial is gradually rotated 90-degrees counterclockwise from the vertical center
  • Full sweep display
  • Battery ignition coil signal
  • An illuminated ring provides easy night-time readability
  • Overvoltage and reverse polarity protection
  • Fully-sealed bobbin assembly to house the gauge motor
  • IP 66 rated front enclosure with dust-proof in the rear
  • SAE and ISO-standards compliant
  • Operating temperature: -40 degree F (-40 C) to + 185 degree F (85 C)

Specifications

Gauge Line: Deluxe
Gauge/Item Name: Tachometer Gauge
Gauge/Item Type: Electrical Gauge
Type Description: Sidewinder Tachometer (electrical)
Diameter, in: 3-3/8"
Volt/Watt/Current: 12 V
Prop 65 Yes/No: Yes
Scale Range: 0-8000 rpm
Signal: Battery ignition
Notes: Battery ignition signal tachometer."Sidewinder" tachometer with graduations rotated 90° counterclockwise from vertical center.For sending unit options, please see the Senders & Sensors section.12V or 24V light kits are sold separately. These are available for 5/8" and 1/2" light holes, in single-wire (grounds to gauge case) or two-wire (when ground cannot be made via gauge case) configurations. Please see Accessories section for available light kits, panel kits, and other options.

In the Box

Guides & Accessories

Reviews

  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getReviews, 11.45ms
  • REVIEWS, PRODUCT
  • bvseo-msg: HTTP status code of 404 was returned; HTTP status code of 404 was returned;

Questions & Answers

  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getContent, 39.06ms
  • QUESTIONS, PRODUCT
  • bvseo-msg: HTTP status code of 404 was returned;
Glossary
Unsure of a term? Look it up on our Glossary powered by The Garage
Stewart Warner Tach Sw Deluxe 8000 Side Winder 82181
$173.99
In Stock
