Tuxedo Distributors 12000 lb Two Post Floor Plate Lift TP12KFX

Product Overview:

Description

Tuxedo, Two Post Floor Plate Lift

The new TP12KFX Two Post Floor Plate Lift has been redesigned and now come standard with low profile drop-in adjustable swivel pads with height adapters, internal hose routing, padded overhead shut-off bar with kill switch, reduced overall width, and rubber door guards, making this model some of the best heavy duty Two Post Lift values in the industry.

Features

  • 12,000 lbs capacity
  • Symmetric arms
  • Rubber door guards
  • Chain drive cylinders
  • Dual point lock release
  • Auto arm restraint system
  • Spin up lift pads
  • Stackable adapters included
  • Internal hose routing

Warranty

1 Year Manufacturers Warranty

Specifications

Lift Model TP12KFX
Capacity 12,000 lbs.
Height Overall 121-1/2"
Width Overall w/ Power Unit 147-7/8"
Max Lift Height 76-1/2"
Width Between Columns 120-5/16"
Min. Pad Height 5"
Drive Thru Clearance 109"
Lifting Speed 45S
Asymmetric / Symmetric Symmetric
Clear Floor / Floor Plate Floor Plate
Short Arm Reach – min/max 37" – 52-1/2"
Long Arm Reach – min/max Same
Narrow Bay Setting NA
Max Load Per Arm 3,000 lbs.
Ship Weight 2,460 lbs
Power 220V – 20 AMP – 1 PH
