Yost Model 45C 4-1/2 Inch Tradesman Combination Pipe and Bench Vise with Swivel Base
Lifetime Warranty Included
100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.
- • Lifetime Tech Support
Product Overview:
Description
The Yost 45C 4.5 Inch Tradesman Series Industrial Grade Bench Vise has swivel base, 4.5" nominal top jaw width, and 0.125"- to 2.5"-diameter pipe capacity provides clamping action for medium-duty applications. The 360-degree swivel base adjusts the direction of the jaws for proper placement and locks in place. This Heavy-Duty Combination Pipe and Bench-Mount Vise has Ductile iron body that provides strength for extended life, and acts as an anvil and an additional work surface. Top jaws are reversible and have a grooved surface on one side for enhanced grip, and a smooth side on the other for handling delicate items. Pipe jaws adjust horizontally and vertically, are set back to prevent interference with top jaw use, and can be replaced when worn. This tool Conforms to Fed. Spec. GGG-V-410B Type IV and meets NSN 5120-00-293-0110 standards.
- Meets NSN 5120-01-457-1004
- Lifetime Casting Warranty
- 65,000 PSI Tensile Ductile Iron Body Parts
- Medium Duty Vise Excellent for General Purpose Service or Maintenance
- Replaceable Hardened Steel Pipe Jaws
- Reversible Hardened Steel Serrated and Smooth Jaws
- Large Anvil
- Interlocking Swivel Base With 360 Degree Motion
- Two Lockdowns
- Pipe Jaws Set Back to Allow for Machinist Gap
- Pipe Jaws are Designed to Grip Pipe Securely
- Design Helps Prevent Pipe Marring Crushing or Bending
- No Pinch Main Handle
Yost Vises has been producing high-quality vises and vise accessories since 1908. We supply our products to both large distributors and individual craftsmen throughout the world ranging from industrial-grade vises, professional-grade vises, workshop-grade vises, light to heavy-duty vises, multifunction vises, welding vises, etc. Our products meet or exceed the Industrial Standard of Federal Specification GGG-V-410A, providing consumers with quality products that last for years at a great price.
Warranty
Specifications
Model Number: | 45C |
Jaw Width (nominal inches): | 4.5 |
Jaw Opening (nominal inches): | 4.5 |
Throat Depth (nominal inches): | 4.5 |
Min Pipe Capacity (nominal inches): | 0.125 |
Max Pipe Capacity (nominal inches): | 2.5 |
Base: | Swivel |
Material: | Ductile Iron |
NSN: | NSN 5120-01-457-1004 (5120014571004) |
Packaging Dimensions: | 16 inches x 8 inches x 13 inches |
Shipping Weight (lbs): | 44 |
Country of Origin: | Taiwan |
In the Box
Contents
(1) Yost Model 45C 4-1/2 Inch Heavy Duty Combination Pipe and Bench Vise
