Item # 22467 BRAND: Earl's

Earls 90 Degree UltraPro Hose End -6 AN Twist-on (Dynamic S

-6 AN Twist-on (Dynamic Swivel) 90 Degree Bent Tube Hose-End
-6 AN Twist-on (Dynamic Swivel) 90 Degree Bent Tube Hose-End
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getAggregateRating, 18.75ms
  • REVIEWS, PRODUCT
  • bvseo-msg: HTTP status code of 404 was returned;
$33.06
Loading...
Save for Later
-6 AN Twist-on (Dynamic Swivel) 90 Degree Bent Tube Hose-End

100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.

  • • 90 Day Returns
  • • Lifetime Tech Support
Earls 90 Degree UltraPro Hose End -6 AN Twist-on (Dynamic S
main product photo

Product Overview:

Description

Earl's UltraPro Series hose-ends are manufactured from premium materials to be light weight and rugged and are perfectly matched to Earl's UltraPro Series hose. Earl's UltraPro Series hose-ends feature ultra high-strength 2024-T8 aluminum in high-stress components, and fluoroelastomer internal seals which are chemically resistant to all known fuels, oils, and coolants. They feature brazed bent tubes for unmatched strength and all unnecessary weight has been eliminated from Ultra-Pro components.

Features:

  • Available Dynamic Swivel™ technology used in selected hose-ends allows 360 degrees of rotation of installed line after installation!
  • Internal seals are a fluoroelastomer material which is resistant to all known fuel, oil and coolant!
  • Traditional Mil-Spec Bent tube design for unmatched strength and flow!
  • UltraPro bent tube hose-ends are dip-brazed for a permanent and robust bond!
  • Designed to withstand harsh environments, brutal vibration, high flow requirements and extreme pressures!
  • Black Anodized
  • Assembled with an olive that threads onto the double-helix ribbed inner liner of the hose for positive engagement and retention of the hose-ends!
  • High stress components are made of high-strength 2024-T8 grade aluminum instead of 6061-T6 aluminum used by competitors!
  • Available in Twist-on and Crimp-on styles for more plumbing options at home or at the track!
  • SAE port, jump size, and Wiggins connector adapter/hose-ends available
  • Straight, 30º, 45º, 60º, 90º, 120º, 150º, and 180º angles available

Warranty

1 Year Manufacturers Warranty

Specifications

<b>Adjustable:</b> Yes<br /> <b>AN Thread:</b> 6 AN<br /> <b>Angle:</b> 90 Degree<br /> <b>Assembly Method:</b> Twist On<br /> <b>Brand:</b>Earls<br /> <b>Compatible Hose:</b> UltraPro<br /> <b>Emission Code:</b> 5<br /> <b>Finish:</b> Anodized Black<br /> <b>Fitting to Hose Mate Type:</b> Twist On<br /> <b>Hose End Family:</b> UltraPro - Twist On<br /> <b>Hose End Series:</b> 62<br /> <b>Material:</b> Aluminum<br /> <b>Product Type:</b> Twist-On Hose Ends<br /> <b>Reusable:</b> Yes<br /> <b>Swivel:</b> Yes<br /> <b>Part Number:</b> 629106ERL<br /><br /> <b>EMMISIONS</b><br><br> <p>This part is legal for sale or use on Emissions Controlled Vehicles, Uncontrolled (Non-Emissions Controlled) Vehicles, and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations.</p>

In the Box

Contents

(1) Earls 90 Degree UltraPro Hose End -6 AN Twist-on (Dynamic Swivel) - Black 629106ERL

Guides & Accessories

Instructions

<p><a href="https://documents.holley.com/199r10852.pdf" target="_blank"><i><b>Instructions for UltraPro Stainless Steel Hoses</b></i></a></p> <p><a href="https://documents.holley.com/199r10853.pdf" target="_blank"><i><b>Instructions for UltraPro Polyester Hoses</b></i></a></p> <p><a href="https://documents.holley.com/199r11133.pdf" target="_blank"><i><b>Instructions for Part# 629106ERL</b></i></a></p> ***Note: All UltraPro hose assemblies must be pressure tested prior to use.
