Item # 31733 BRAND: Rockwood

Rockwood® 3/8 InchNPT Air Filter Regulator

Rockwood 3/8” NPT Air Filter Regulator
Rockwood 3/8” NPT Air Filter Regulator
Rockwood® 3/8 InchNPT Air Filter Regulator is rated 5.0 out of 5 by 1.
  • y_2021, m_10, d_14, h_18
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.19
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_1
  • loc_en_US, sid_31733, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getAggregateRating, 58.59ms
  • REVIEWS, PRODUCT
$38.99
Loading...
Save for Later
Rockwood 3/8” NPT Air Filter Regulator
  • 90-Day Returns
  • Technical Support
Rockwood® 3/8 InchNPT Air Filter Regulator

Description

The Rockwood 3/8” NPT Air Filter/Regulator includes a high-capacity, drainable Coalescing Filter and Bowl to trap moisture and other impurities from a compressed air supply. The Regulator features a 0 to 160 PSI Gauge. Also included is an integral mounting bracket for secure mounting.

Specifications

• 3/8” FNPT Inlet
• 3/8” FNPT Outlet
• Maximum Input Pressure: 215 PSI
• Maximum Output Pressure: 150 PSI
• Maximum 140°F (60°C) service temperature
• Flow Rate: 88 CFM
• Filters Down to 5 Microns

Contents

(1) 3/8” FNPT integral Filter/Regulator with Drain Valve
(1) Mounting Bracket
(1) Pressure Gauge

Accessories

Rockwood 3/8 in. Npt Air Filter Regulators Pressure Regulator With Condensate Discharge Filter And Pressure Gauge Connections

Application Tips

Drainable Coalescing Filter And Bowl To Trap Moisture And Other Impurities From A Compressed Air Supply

Safety Information

Read Instructions thoroughly read and understand these product instructions before using this equipment. Failure to follow all warnings can result in tool damage or serious physical injury. Keep product instructions for future reference.

Customer Reviews

Rated 5 out of 5 by from Great Regulator Easy install and very well made. It’s low priced but not cheaply made. I was pleasantly surprised at the construction which is common with Eastwood products; well made and low priced. If you need a regulator/filter, look no further.
Date published: 2019-01-10
  • y_2021, m_10, d_14, h_18
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.19
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_1
  • loc_en_US, sid_31733, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getReviews, 36.87ms
  • REVIEWS, PRODUCT

Questions & Answers

Is it made in China?

Asked by: Thomas
This product is manufactured in Taiwan.
Answered by: SeanW
Date published: 2020-07-03

Can the gauge be mounted on the opposite side to accommodate system flow right to left?

Asked by: Dave
Unfortunately the gauge cannot be mounted on the opposite side.
Answered by: Scott C
Date published: 2018-09-07
  • y_2021, m_10, d_15, h_18CST
  • bvseo_bulk, prod_bvqa, vn_bulk_3.0.19
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_2
  • loc_en_US, sid_31733, prod, sort_[SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getContent, 83.86ms
  • QUESTIONS, PRODUCT
Rockwood® 3/8 InchNPT Air Filter Regulator
$38.99
In Stock
