Rockwood 3/8” NPT Air Filter Regulator

Rockwood 3/8” NPT Air Filter Regulator

Item #31733 Brand: Rockwood

Details

The Rockwood 3/8” NPT Air Filter/Regulator includes a high-capacity, drainable Coalescing Filter and Bowl to trap moisture and other impurities from a compressed air supply. The Regulator features a 0 to 160 PSI Gauge. Also included is an integral mounting bracket for secure mounting.

More info...

(1) 3/8” FNPT integral Filter/Regulator with Drain Valve
(1) Mounting Bracket
(1) Pressure Gauge

Specifications

• 3/8” FNPT Inlet
• 3/8” FNPT Outlet
• Maximum Input Pressure: 215 PSI
• Maximum Output Pressure: 150 PSI
• Maximum 140°F (60°C) service temperature
• Flow Rate: 88 CFM
• Filters Down to 5 Microns

Instructions

Click here for product instructions

Safety

Read Instructions thoroughly read and understand these product instructions before using this equipment. Failure to follow all warnings can result in tool damage or serious physical injury. Keep product instructions for future reference.
