Product Overview:

Description

With nearly 45" of rise from the flush-mounted position, the MDS-6LPF is a world-class performer in the mid-rise lift class. There's no better way to get this much power and height from a fully collapsed, zero-footprint design.

The MDS-6LPF Walks the Walk

If you’re looking to flush-mount your lift in the floor for a smooth sub-surface installation, be sure to choose the MDS-6LPF. Sharing all the same features of the MDS-6LP, our space-saving flush-mount design is the ideal way to keep garage lift equipment parallel with your flooring.

Stronger lift from a collapsed position
A pneumatic "kick" powers the lift up from the collapsed height, which for a flush-mount means it goes from zero-footprint to full rise in about 45 seconds. This extra boost ensures a more even lift in the early inches, and the hydraulics take over from there.

Four hydraulic cylinders
We put enough power in this scissor lift to ensure it handles that 6,000-lb. load without a hitch. Fluid traveling to all four cylinders goes through a flow divider to ensure equal pressure at all times. The platforms are always going to rise and descend simultaneously every inch of the way.

Solid-steel safety lock bars
With three locking positions to choose from, the MDS-6LPF offers incredible work height versatility. If you've got a pit, the mid-rise design becomes a full-height service lift.

Convenient stainless-steel pneumatic cylinders
Instead of spring releases, which tend to wear over time, our flush-mount design features air cylinders pressurized to 50 psi, 10-CFM. A simple hand pump or air compressor will have the cylinders ready to go in seconds.

A push-button safety lock release system
The push of a button releases all locks simultaneously and quickly lowers the scissor lift platforms down to their flush-mounted starting position.

Hinge-point features Zerk grease fittings
Zerk grease fitting are long-lasting, self-lubricating and simple to maintain. They'll virtually last forever with minimal care.

Durable, cushioned rubber contact blocks
Hard rubber blocks come standard with your lift purchase. No small, dinky pads here. These rugged lifting tools will protect your vehicles' frames and are guaranteed not to slip when properly placed during lifting procedures.

NOTE: The lift platform and contact blocks allow lifting of most unibody and frame contact undercarriages at recommended manufacturer pick-up points on most vehicles. Be sure to compare your vehicle specifications, including ground clearance and overall height, with the specifications shown before you purchase.

Detailed installation and maintenance instructions
We include a full installation and training/service manual, along with safety decals and stickers, for your convenience.

Features:

  • Each lift platform features four solid steel-scissor frame support bars, making it one of the strongest mid-rise lifts in its class
  • Dual master hydraulic cylinder combines with dual equalizing cylinders to provide a safe and level 6,000 pound lifting capacity
  • Soli-steel safety lock bars engage automatically during ascent
  • Convenient stainless-steel pneumatic cylinders simultaneously release safety locks during descent with a simple push of a button. (NOTE: Requires min. 50 psi, 10-CFM air source at time of installation.)
  • A push-button safety lock release system is operated away from the lift and allows operators to safely deactivate the locks without the need to push or pull cumbersome release bars or lock release handles
  • Hinge point features Zer

Warranty

Warranty

Specifications

Lifting capacity: 6,000 lbs. (2,722 kg)
Lifting Height: 43'' (1,093 mm) / ( minus 4-3/8'' for sub-surface flooring)
Lifting Height + Blocks: 45'' (1,144 mm) / ( minus 4-3/8'' for sub-surface flooring)
Lift Platform Dimensions: 19'' x 67'' (484 mm x 1,701 mm)
Width Between Platforms: 40'' to 46'' (1,018 mm to 1,168 mm)
Overall Width: Adjustable
Overall Length: 67'' (1,701 mm)
Lowered Height: Flush with ground
Lifting Time: 35 seconds
Motor: 110 or 220 VAC / 60 Hz / 1 Ph

Shipping & Handling

  • Delivery Time: This item ships directly from the manufacturer - Please allow 2-3 weeks for delivery time
  • Residential Delivery: This item may only be shipped to a business address and a forklift must be available to unload.
  • Delivery: Will be delivered truck and will require a forklift to unload. You must have a forklift to unload from truck.

https://www.bendpak.com/BendPak-Products-Flatbed-Exclusive.pdf

https://www.bendpak.com/BendPak-Delivery-Information-Form.pdf

Fork Lift Required for Delivery

In the Box

Guides & Accessories

Instructions

<p><a href="https://www.bendpak.com/MDS-6-Series-Mid-Rise-Lift-Manual-5900030-BendPak.pdf" target="_blank"><i><b>User Manual for Part # 5175227</b></i></a></p>

Reviews

  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getReviews, 3.97ms
  • REVIEWS, PRODUCT
  • bvseo-msg: HTTP status code of 404 was returned; HTTP status code of 404 was returned;

Questions & Answers

With the unit all the way up. With a vehicle on it. What is the minimun height required

Asked by: Olegasser
I have 10&rsquo; ceilings and have 2-3 foot clearance with most vehicles. &nbsp; With a full size SUV I may have 2 foot.&nbsp;
Answered by: JMAC
Date published: 2021-11-29
