QuickJack 5000TL-220V with Wall Hangers Set and Pinch Weld Blocks Set Lift 5175418
Manufacturer Warranty Included
100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.
- • Lifetime Tech Support
Product Overview:
Description
QuickJack 5000TL-220V Vehicle Lift with Pinch Weld Blocks Features:
- 5,000-pound capacity
- 24-inch maximum lift height
- 70-inch frame length
- Pinch weld block set for unibody vehicles
- Auto-locking safety bars
- Push-button operation
- Includes wall hangers
- Requires 220-volt power supply
- One-year manufacturer’s warranty
With the QuickJack 5000TL Portable Vehicle Lift, you can always get a car off the ground when you need to. Replace floor jacks and stands with this 220V hydraulic car lift system that reaches its 24-inch max height in just 30 seconds. You’ll have plenty of space to work underneath street cars, race cars and light-duty trucks. The next generation of vehicle lifts will support up to 5,000 pounds. For modern cars that have a unibody or pinch weld frame, the included urethane block set spreads out the pressure to reduce the risk of damage.
A compact car lift is a simple and affordable alternative to jack stands. It has an easy push-button operation with one hand and dual-position safety bars that automatically lock into place, If you have a longer vehicle or light pickup truck, consider the QuickJack 5000TL Extended Light with an extra six inches of length. Learn more about QuickJack auto lifts in the Eastwood Garage and see how they help you Do the Job Right.
Specifications
Lifting Capacity: | 5,000 lbs. |
A - Lowered Height (Frame Only): | 3" |
B - Lowered Height (W/ 2" Block): | 3.5" |
C - Frame Only: | 17.6" |
D - Lifting Height (W/ 2" Block): | 21" |
E - Lifting Height (W/ 3" Block): | 22" |
F - Max. Height: | 24" |
G - Lifting Height (W/ Adapters): | 24" |
H - Lifting Height (W/ Adapters + Pin): | 26.75" |
I - Lift Point Spread (Max): | 60" |
J - Lift Point Spread (Min): | 37" |
K - Frame Width: | 11" |
L - Frame Length: | 70" |
Frame Weight: | 78 lbs. |
Time To Full Rise: | 30 seconds |
Power Unit Weight: | 15 lbs. |
Shipping Dimensions (ea. frame): | 73.5" (L) x 15.25" (W) x 5" (H) |
Total Shipping Weight: | 240 lbs. |
Package Includes: | Lift, Wall Hangers Set and Pinch Weld Blocks Set |
In the Box
Contents
- 5000TL Left Frame Assembly
- 5000TL Right Frame Assembly
- 1x Hydraulic power unit with control
- 4x Medium rubber lift blocks (2")
- 4x Tall rubber lift blocks (3")
- 2x Short hydraulic hoses
- 2x Long hydraulic hoses
- 2x Frame-positioning handles
- Wall Hangers Set
- Pinch Weld Blocks Set
- Fittings and thread tape for setup
- Instruction manual
