Eastwood 20 Ton Hydraulic Shop Press
- High Quality Steel Construction
- Pro Quality 20 Ton Hydraulic System
- Meets ASME 2014 Standards
- Use for Many Medium and Heavy Duty Applications
- High Quality Steel Construction
- Pro Quality 20 Ton Hydraulic System
- Meets ASME 2014 Standards
- Use for Many Medium and Heavy Duty Applications
- High Quality Steel Construction
- Pro Quality 20 Ton Hydraulic System
- Meets ASME 2014 Standards
- Use for Many Medium and Heavy Duty Applications
1 year Warranty Included
100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.
- • 90 Day Returns
- • Lifetime Tech Support
Price for all checked items:
Product Overview:
Description
The Eastwood 20 Ton Hydraulic Bench Press is excellent for many mechanical procedures requiring a strong linear pressing force for disassembly or assembly operations.
- High Quality Steel Construction
- Pro Quality 20 Ton Hydraulic System
- Meets ASME 2014 Standards
- Floor Standing Model that can be used for many medium and heavy duty applications
This Bench Press has a generous 7-1/4” Ram Stroke and adjustable 2.3 to 40” vertical working range can easily accommodate many ball joint, u-joint, bearing, bushing and gear pressing projects. The convenient Foot Pedal feature provides a choice of hands-free, foot actuated operation or the standard, hand operation pump function.
This Eastwood 20 Ton Shop Press ships in two boxes. Both boxes will be shown in your shopping cart and are needed to assemble a complete press.
Warranty
Specifications
| Hydraulic Pump Capacity: | 20 Tons (40,000 lbs.), [18,144 kg] maximum |
| Hydraulic Ram Stroke: | 7.25" [185 mm] |
| Vertical Working Range: | 2.3 to 40" [58 - 1016mm] |
| Arbor Depth: | 4" [101 mm] |
| Arbor Width: | 21.25" (540mm) |
| Force Gauge units: | 0-30 U.S. Tons, 0-28 Metric Tons |
| Ram Size: | 48mm |
| Workpiece Plate Construction: | 30mm Steel, Black Powdercoat |
| Frame Construction: | 5mm Welded Steel, Black Powdercoat |
| Workpiece Support Pins Construction: | 18mm Steel, Zinc Plated |
| Hydraulic Pump: | Includes Foot Pedal and Handle |
In the Box
Contents
Box 1 Contents
(2) Main Frame Sides
(2) Upper Frame Beams
(2) Base Rails
(1) Lower Cross Member
(4) Angle Braces
(1) Foot Pedal
(1) Linkage Arm
(2) Table Support Pins
(1) Table Front Half
(1) Table Back Half
(2) Table Spacers
(1) Pump Handle
Box 2 Contents
(1) Hydraulic Pump Unit
(1) Yoke Plate
(1) Ram
(1) Force Gauge
(1) Nylon Seal
(4) Table Support Pin Clips
(1) Foot Pedal Spring
(1) Foot Pedal Pivot Shaft Ass’y
(2) Spring Eyelet Ass’y
(2) Linkage Clevis Pins
(2) Cotter Pins
(2) Arbor Plates
Hardware
This Eastwood 20 Ton Shop Press ships in two boxes. Both boxes will be shown in your shopping cart and are needed to assemble a complete press.
Guides & Accessories
Instructions
Click here for product instructions
Safety Information
Accessories
54446 Eastwood 20T Hydraulic Ram (54442)
54449 Eastwood 20T Bed Frame Pin and Clip - Pair (54442)
54452 Eastwood 20T Hardware Kit (54442)
