Eastwood Stitch Weld Magnets is rated 4.6 out of 5 by 32.
Rated 5 out of 5 by from Wow ,very powerful I only work on aluminum...aircraft...doing paper or cupboard patterns I just use metal under the pattern and what ever I am making a pattern of and the magnets on top.Another good use is on a stomp shear ,after you get the flat sheet exactly where you want it in the sheer use the magnets to hold the metal sheet in place so it won't move before the sheer hold down comes down onto the sheet....(I think most car people refer to the sheet as a panel)
Date published: 2019-01-22
Rated 5 out of 5 by from WOW! Worked GREAT Best $20 I ever spent. I just got them, and they paid for themselves the first time I used them. They did a PERFECT job of holding the patch panels perfectly flush.
Date published: 2019-01-18
Rated 5 out of 5 by from Great magnets These magnets work great and are small enough to use on small patches. The only thing is they tend to close the gap between the patch and base panel. An easy solution I had was to stick a panel saw blade in as spacers until the first few beads are welded.
Date published: 2018-11-04
  • y_2019, m_5, d_19, h_22
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_32
  • loc_en_US, sid_20421, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood

How much is the shipping weight for 1 Qty? It looks a weird question, but it's very important to me :)

Asked by: Mohammad
Shipping weight is a third of a pound.
Answered by: Scott C
Date published: 2019-02-23

I bought a set and I've noticed two things. 1) They seem to screw up the weld so you better not do any more than a tack if you are within a few inches of them. This is mig welding. Is that normal? 2) They chip if snapped together. Normal?

Asked by: 31Dodge
The strong magnetic pull can slightly pull your weld if you're too close. Second with any magnet they can chip on the edges as they snap together.
Answered by: Scott C
Date published: 2019-04-16

Do these magnets come in some sort of protective case?

Asked by: dan0
These are shipped in a cardboard box with dividers between them.
Answered by: S Church
Date published: 2019-02-23

Hey Guys, Heat is the enemy of these magnets.  It destroys the magnetic capability.  Are these magnets any different?

Asked by: njmj
These magnets are designed to be considered a consumable and will eventually wear out. They are very strong though and will hold up for quite some time.
Answered by: S Church
Date published: 2019-02-23
  • y_2019, m_5, d_19, h_22CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.12
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_4
  • loc_en_US, sid_20421, prod, sort_[SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood

Eastwood Stitch Weld Magnets

Eastwood Stitch Weld Magnets

Item #20421

Super strong magnets hold patch panels in place, perfect for blind repairs
Quantity: close

In stock

Only $23.99

Sale $21.97


< Back


Super strong magnets hold patch panels in place from the outside, perfect for blind repairs.

  • 8 pack of strong rare earth magnets
  • 1/2 inch (12.7mm) diameter disc
  • Strong enough to hold patch panels
  • Hold flush patches in perfect alignment
  • Position panels with no gaps
  • Perfect for blind repairs

If you have ever tried to weld a patch panel into a spot where you can’t access the back side, these rare earth magnets are a life saver. These nickel plated super strong magnets come 8 to a package, and each one measures just 1/2 inch (12.7mm) in diameter, but are strong enough to support several pounds. Place them every few inches at the edge of your panels and you can position the panel with no gap, or the perfect gap for whichever welding method you are using. Use a few of these magnets and never feel like you need 3 hands again.

Eastwood Stitch Weld Magnets

These 12.7mm diameter x 19mm length rare earth neodymium nickel plated magnets are design to offer superior panel alignment when welding patch panels. With N35 strength, high heat resistant of up to 200F, these magnets will keep both panels in perfect alignment when stitch welding. 8 pieces are included in this kit in which are used approximately 2 inches apart along your weld seem. The magnets will keep both panels level and aligned, while eliminating panel gaps, distortion and raised/recessed areas. For use when MIG, TIG or Gas welding to hold panels while tack welding material.

More info...
< Back


12.7mm diamter x 19mm length, 8 N35 strength Neodymium rare earth magnets


Magnets are nickle plated to eliminate corrosion. In use the nickle plate may chip and the magnets may need to be replaced after time.


1 Year Warranty

100% Satisfaction Guarantee

Eastwood Offers Free Lifetime Technical Support

Click here for product SDS information

Attention California Residents - Proposition 65

Proposition 65 Warning WARNING - Cancer and Reproductive Harm - www.P65Warnings.ca.gov
