Item # 20274 BRAND: Maxx Power

Maxx Power Ford Chrysler Style Tri Flow Aluminum Radiator 22 Inch

Special 3 pass design for Ford or Chrysler motors, produces temps up to 24 degrees lower than other aluminum radiators
Special 3 pass design for Ford or Chrysler motors, produces temps up to 24 degrees lower than other aluminum radiators
Maxx Power Ford Chrysler Style Tri Flow Aluminum Radiator 22 Inch is rated 4.7 out of 5 by 66.
  • y_2024, m_3, d_3, h_9
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.38
  • cp_1, bvpage1
  • co_hasreviews, tv_5, tr_61
  • loc_en_US, sid_20274, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getAggregateRating, 35.86ms
  • REVIEWS, PRODUCT
$274.99
Loading...
Loading...
Save for Later
Special 3 pass design for Ford or Chrysler motors, produces temps up to 24 degrees lower than other aluminum radiators

90 day Warranty Included

100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.

  • • Lifetime Tech Support
Maxx Power Ford Chrysler Style Tri Flow Aluminum Radiator 22 Inch

Product Overview:

Description

Maxx Power Tri Flow Radiators are designed to eliminate your overheating issues. Temperature reductions of up to 24 degrees F over your current temp are not uncommon. Independent lab tests with LS motors have shown 20 degrees F drop in temp over conventional aluminum radiators and even more over OE copper/brass.

  • Designed to eliminate overheating issues
  • Temperature reductions of up to 24 degrees F
  • Fully TIG welded 6061 aluminum tanks and core
  • Unique design passes coolant though core 2x more than other radiators

It was developed with 2 rows and a 1 inch oval tube core and a unique coolant path that routes the coolant through the radiator core 3 times and increases turbulent flow while passing the coolant in front of the fan 3 times. Traditional radiators only pass the coolant 1 time in the front of the fan. This is what makes this Radiator the best on the market.

Fully TIG welded 6061 aluminum tanks, with 2 inch mounting tabs on each side make mounting in your car or truck easy, no matter what it is. Configured for universal fit with 1.5 inch inlet and 1.75 inch outlet, a machined radiator cap opening and overflow nipple on passenger side, plus a welded 1/4 NPT bung that can be used for a LS steam port or temperature sender up top, and another one for the petcock. Complete the cooling system with no fastener aluminum shroud (#20296) and 14 inch electric fan (#20244) specifically sized for MaxxPower radiators.

Warranty

365 days warranty.

Specifications

  • Configured with proper inlet and outlet for Mopar and Ford motors
  • Radiator holds 1.3 gallons of coolant
  • 1 1/2 inch inlet on passenger side, 1 3/4 outlet on driver side
  • 22in wide x 19in high x 2in thick
  • Universal 2 inch mounting tabs on both sides
  • Machined radiator cap fitting on passenger side with overflow nipple
  • 1/4 NPT bung for LS steam port/temp sender fitting on passenger side
  • 1/4 NPT bung for petcock drain on driver side

In the Box

Contents

(1) 20274 Maxx Power Tri Flow 22 In Aluminum Radiator

Guides & Accessories

Instructions

Click here for product instructions

Click here to download product specifications.

Click here for how-to video on measuring and installation

Safety Information

Never open a radiator that the engine has been allowed to reach operating temperature. Serious injury can occur from scalding coolant or steam.

Click here to see safety products

Application Tips

Universal

Reviews

Rated 5 out of 5 by from Cooler is better Nice product. Temperature dropped 15 degrees thx
Date published: 2023-06-28
Rated 5 out of 5 by from Very nice using it for my 355sbc, keeps it cool when not moving for long periods of time.
Date published: 2023-06-22
Rated 5 out of 5 by from Automotive Instructor for 35 years. This radiator is well built and has plenty of capacity for the small block Chevy application in our 1964 Ford PU. This cost less than half of the other options that I researched.
Date published: 2023-05-04
Rated 5 out of 5 by from great radiator! This is a great radiator!! very happy with the build quality and performance..
Date published: 2023-04-16
Rated 5 out of 5 by from How good is the Tri-flow radiator? Used the 26in in my Camaro, love it, it does exactly what they described. The only problem I have is the bottom hose port should be straight out instead of a 30 degree angle. Other than that works great.
Date published: 2023-01-30
Rated 5 out of 5 by from Cool Radiator looks like a great product. good quality. I have not had a chance to install it yet.
Date published: 2022-09-30
Rated 5 out of 5 by from Worth every dollar and better than a lot more expensive radiators online Very good quality radiator and easy to mount on a race car. Packaged with love not one fin was messed up when i got it.
Date published: 2022-08-06
Rated 5 out of 5 by from Awesome radiator Awesome radiator, keeps my SBC at least 20 degrees cooler than my old single pass aluminum radiator
Date published: 2022-07-18
  • y_2024, m_3, d_3, h_9
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.38
  • cp_1, bvpage1
  • co_hasreviews, tv_5, tr_61
  • loc_en_US, sid_20274, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getReviews, 22.06ms
  • REVIEWS, PRODUCT

Questions & Answers

For a 1990 jeep wrangler yj with 2008 5.3 vortec what radiator do you recommend

Asked by: Eddie
Our Tri flow. Go to our website search Tri flow. it depends on measuring the width. Height is standard 19" and 2.2 inches thick
Answered by: Anonymous
Date published: 2024-01-22

I've got a 66 Pro Street Mustang with a 871 blown 351C. Blowers make a lot of heat even when you aren't leaning on them so heating up has always been big issue. The Griffin we used didn't cut it. Will the tri flow rad work for low RPM use.

Asked by: Hotrods512
The tri-flow reduces heat 24 degrees while reducing water temp.
Answered by: Anonymous
Date published: 2023-12-06

What water pump is recommended?

Asked by: Cole
Depending on the vehicle and motor
Answered by: Anonymous
Date published: 2023-12-06

1973 nova , 350 engine , still using mechanical fan and also a 17" pusher , has external trans cooler mounted on front of radiator , , can I keep same setup and use the tri flow?

Asked by: Wayneno
Yes, you may have to fabricate mounting brackets for your trans cooler.
Answered by: Anonymous
Date published: 2023-04-17

What size are the tubes in this radiator ?

Asked by: Mattman
It was developed with 2 rows and a 1 inch oval tube core and a unique coolant path that routes the coolant through the radiator core 3 times and increases turbulent flow while passing the coolant in front of the fan 3 times. Traditional radiators only pass the coolant 1 time in the front of the fan. This is what makes this Radiator the best on the market. https://www.eastwood.com/images/pdf/20150Q_inst.pdf
Answered by: Anonymous
Date published: 2023-03-24

Your radiators are significantly smaller than the one I have in my vehicle. Mine is 33 w by 3. It appears I would be reducing the amount of water for my engine in your radiator. So your radiator would be equipped to cool efficiently with less water?

Asked by: Bob 1701
Yes it will cool better but it might not hold that much less coolant than your bigger radiator due to these being a 2 core 3 pass design.
Answered by: Sean H
Date published: 2022-08-30

Does the 22” radiator come with automatic trans cooler connections also would it keep a big block cool?

Asked by: Ratso
Yes, the connection ports are on these radiators upon arrival. These will all cool up to 500hp at a max.
Answered by: Kelly H
Date published: 2022-08-23

Can the radiator be ordered with the brackets reversed/flipped so that the mounting flanges are flush with the coolant inlet/outlet side? I need to recess the radiator into the mounting frame away from the engine. Thanks

Asked by: Brett
No, this radiator comes as-is and can not be modified before shipping out.
Answered by: ZachC
Date published: 2022-06-21
