Item # 20411 BRAND: Eastwood

Eastwood Versa Bend Forming Brake

Versa Bend Forming Brake Option for 14042
Versa Bend Forming Brake Option for 14042
Eastwood Versa Bend Forming Brake is rated 3.6 out of 5 by 5.
  • y_2023, m_3, d_22, h_23
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.34
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_4
  • loc_en_US, sid_20411, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getAggregateRating, 133.84ms
  • REVIEWS, PRODUCT
$79.99
Loading...
Loading...
Save for Later
Versa Bend Forming Brake Option for 14042

1 year Warranty Included

100% Satisfaction Guarantee Since 1978
We stand behind our solutions and customers.

  • • 90 Day Returns
  • • Lifetime Tech Support
Eastwood Versa Bend Forming Brake
main product photo
Frequently Bought Together

Price for all checked items:

Product Overview:

Description

The Eastwood Versa-Bend Forming Brake is designed to be used with the Eastwood #14042 Versa-Bend 20" Sheet Metal Brake to create multiple bend channel shapes as narrow as 3/8" (9.5mm).

  • Works with 20 gauge steel and 18 gauge aluminum
  • Use on panels up to 20" wide
  • Excellent for creating hard to form parts
  • Create window channels, floor braces, weatherstrip retainers and much more

When the precision machined Versa Bend Forming Brake is teamed with the Eastwood Versa Bend Sheet Metal Brake, you are enabled to make precise bends within 3/8 in of each other up to 90 degrees in 20 gauge sheet steel and 18 gauge aluminum in widths up to 20 Inch. Create floor reinforcement channels and ribs, door sills, sections of corrugated pickup bed floors; truck bedside panels, inner fender structures and much more all with one convenient vise or bench mount tool.

Warranty

90 Day Warranty

In the Box

Contents

20 in sheetmetal brake with hardware included. 2 bolts and 2 washers.

Guides & Accessories

Instructions

Click here for product instructions

Safety Information

Use extreme caution when mounting or dismounting when using a vice or other temporary fixturing arrangement. Personal injury could occur if tool is dropped. Pinch Hazard. Keep fingers away from moving parts when operating. Wear appropriate work gloves and protective clothing. Sheet metal will often have sharp edges which can cause cuts to hands and arms. Wear appropriate eye protection. Metal chips can be ejected during the bending process.

Accessories

32044 Bead Roller
51088 DIY Shrinker/Stretcher Set
13475 Eastwood Electric Metal Shears
11797 Throatless Shear
20199 Eastwood 12 Inch Slip Roll

Reviews

Rated 5 out of 5 by from Perhaps the most versatile brake on the market. I couldn't be happier with the quality, capabilities and price of this brake. Hats-off to the designers! It will produce almost any bend you can imagine. Great for novice or pro.
Date published: 2017-08-23
Rated 5 out of 5 by from benda the metal Works great for me.... I am making small patch repair panels and it works well in conjunction with the sheet metal brake.
Date published: 2016-01-04
Rated 2 out of 5 by from limited use Bought this to bend a 12 inch strip of 0.040 2024-T3 aluminum to 90 degrees. Simply put, The description says it will bend 18 gauge aluminum but it won't. Bending arms bend but the sheet of aluminum does not. The center of the bending angle beam actually bows - not stiff enough to hold shape. Probably good for 0.020 thick aluminum but not much more. Comes without instructions or illustrations of how to set up the bending process.
Date published: 2020-07-06
Rated 1 out of 5 by from Part doesn't fit Hole's don't lineup with brake. They replaced with new one. But that doesn't line up either. Just going to grind off the locators and reweld them . About a half a hole off .
Date published: 2022-01-21
  • y_2023, m_3, d_22, h_23
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.34
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_4
  • loc_en_US, sid_20411, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_eastwood
  • bvseo_sdk, p_sdk, 3.2.1
  • CLOUD, getReviews, 20.61ms
  • REVIEWS, PRODUCT

Questions & Answers

how thick of a material the plate is made of and the height

Asked by: Raja
The plate is 3/8" X 2.5"
Answered by: Bob G
Date published: 2019-12-27
